Surface Mount Extension Handle, Black

Name: Surface Mount Extension Handle, Black
SKU: 732322

$ 31.36

$ 0.00

Save: $

Size:

Unavailable

Please select combo product attributes

The combo subtotal is $,SAVE$

Mounts to the outside of a case
Low profile design, less than 1" thick
Extends 12", handle stops in two positions with the locking tab: fully extended and fully retracted
Approximate weight capacity is 125lbs
Handle has built-in offset to slide past edge extrusions & sides are beveled to reduce impact. Made from engineered glass-filled plastic resin. Recessed mounting holes 1/4" diameter, spaced at 1-1/2" to fit most cases and protect mounting screws. Mounting holes have a knock-out cover. Use only the holes required

MFG Item No: 500-2310900

Material: Engineered Plastic

Color/Finish: Black

Size: Large

Width: 17.30in [439.4mm]

Height: 7.50in [190.5mm]

Depth: 1.31in [33.3mm]

Weight: 2.70lb [1.2 kg]

Country of Origin: China

Package Size: 1

PDF Drawing

DXF File
